Gigabyte A520M DS3H Pure Digital VRM Solution DDR4 Motherboard Price in Pakistan
CPU

1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors (Please refer “CPU Support List” for more information.) Chipset1. AMD A520 Memory1. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory 2. Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 3. Dual channel memory architecture 4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules 5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules 6. Support for Extreme Memory Profile (XMP) memory modules (Please refer “Memory Support List” for more information.) Onboard GraphicsIntegrated Graphics Processor:1. 1 x DisplayPort, supporting a maximum resolution of 5120×2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. 2. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio1. Realtek® Audio CODEC 2. High Definition Audio 3. 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN1. Realtek® GbE LAN chip (1 Gbps/100 Mbps) Expansion Slots1 x PCI Express x16 slot, integrated in the CPU:1. Supporting PCIe 3.0 x16 mode 1 x PCI Express x1 slot, integrated in the Chipset: 1. Supporting PCIe 3.0 x1 mode Storage Interface1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:1. Supporting SATA and PCIe 3.0 x4/x2 SSDs 4 x SATA 6Gb/s connectors, integrated in the Chipset: 1. Supporting for RAID 0, RAID 1, and RAID 10 USBCPU:1. 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 1. 2 x USB 3.2 Gen 1 ports available through the internal USB header 2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors1. 1 x 24-pin ATX main power connector 2. 1 x 8-pin ATX 12V power connector 3. 1 x CPU fan header 4. 1 x system fan header 5. 1 x M.2 Socket 3 connector 6. 4 x SATA 6Gb/s connectors 7. 1 x front panel header 8. 1 x front panel audio header 9. 1 x USB 3.2 Gen 1 header 10. 1 x USB 2.0/1.1 header 11. 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 12. 1 x Clear CMOS jumper Back Panel Connectors1. 1 x PS/2 keyboard/mouse port 2. 1 x DisplayPort 3. 1 x HDMI port 4. 4 x USB 3.2 Gen 1 ports 5. 2 x USB 2.0/1.1 ports 6. 1 x RJ-45 port 7. 3 x audio jacks I/O Controller1. iTE® I/O Controller Chip H/W Monitoring1. Voltage detection 2. Temperature detection 3. Fan speed detection 4. Fan fail warning 5. Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS1. 1 x 128 Mbit flash 2. Use of licensed AMI UEFI BIOS 3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features1. Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Smart Backup System Information Viewer 2. Support for Q-Flash 3. Support for Xpress Install Bundled Software1. Norton® Internet Security (OEM version) 2. LAN bandwidth management software Operating System1. Support for Windows 11 64-bit 2. Support for Windows 10 64-bit Form Factor1. Micro ATX Form Factor; 24.4cm x 24.4cm
